Model

Volts (V)

Power Rating (W)

Impedance (Ohm)

Transformer Size

L

W

H

Mounting Type

M–70001

70

4 – 2 – 1 – 0.5

1.25K-2.5K-5K-10K

INT-41 x 16

43

18

35

“U” Bracket

M–70002

70

5 – 2 – 1 – 0.5

1K-2.5K-5K-10K

INT-41 x 16

43

18

35

“U” Bracket

M–70003

70

8 – 4 – 2 – 1

625-1.25K-2.5K-5K

T-12A x 16

51

19

42

“U” Bracket

M–70004

70

10 – 7.5 – 5 – 2.5

500-666-1K-2K

T-12A x 16

51

19

42

“U” Bracket

M–70005

70

16 – 8 – 4 – 2

312-625-1.25K-2.5K

T-23 x 19

60

22

49

“U” Bracket

M–70006

70

20 – 15 – 10 – 5

250-333-500-1K

T-23 x 19

60

22

49

“U” Bracket

M–70007

70

25 – 20 – 10

200-250-500

T-31 x 25.4

70

29

58

“U” Bracket

M–70008

70

32 – 16 – 8

156-312-625

T-31 x 25.4

70

29

58

“U” Bracket

M–70009

70

45 – 30 – 20

110-167-250

T-31 x 25.4

70

29

58

“U” Bracket

M–70010

70

50 – 30 – 15

100-167-333

T-15 x 31.75

76

35

67

“L” Clamps

M–70011

70

60 – 45 – 30

133-167-222

T-33 x 38.1

84

40

72

“L” Clamps

M–100001

100

5 – 2 – 1 – 0.5

2K-5K-10K-20K

INT-41 x 16

43

18

35

“U” Bracket

M–100002

100

6 – 4 – 2 – 1

1.67K-2.5K-5K-10K

INT-41 x 16

43

18

35

“U” Bracket

M–100003

100

10 – 7.5 – 5 – 2.5

1K-1.33K-2K-4K

T-12A x 16

51

19

42

“U” Bracket

M–100004

100

15 – 10 – 7.5 – 5

666-1K-1.33K-2K

T-23 x 19

60

22

49

“U” Bracket

M–100005

100

20 – 15 – 10 – 5

500-666-1K-2K

T-23 x 19

60

22

49

“U” Bracket

M–100006

100

25 – 20 – 15 – 10

400-500-666-1K

T-31 x 25.4

70

29

58

“U” Bracket

M–100007

100

30 – 20 – 15 – 10

333-500-666-1K

T-31 x 25.4

70

29

58

“U” Bracket

M–100008

100

35 – 30 – 25 – 10

285-333-400-1K

T-31 x 25.4

70

29

58

“U” Bracket

M–100009

100

50 – 40 – 30 – 20

200-250-333-500

T-15 x 31.75

76

35

67

“L” Clamps

M–100010

100

60 – 45 – 30

167-222-333

T-15 x 31.75

76

35

67

“L” Clamps

M–100011

100

75 – 60 – 45

133-167-222

T-33 x 38.1

84

40

72

“L” Clamps

Dimension in mm. Tol: +/- 2mm
